    iP 50-RX Web-Based Power Controller

    Slimline 15A power controller with two IP-addressable outlets and RX surge protection.

    The iP 50-RX is a compact, web-based power controller providing remote management for two individual outlets with integrated RX Series surge and noise protection. It is designed for installations where space is limited, allowing integrators to remotely reboot equipment and protect sensitive electronics without requiring a site visit.

    Request a Quote

    Request A Quote

    Request more information about this product or speak directly with our sales team today.

    This field is for validation purposes and should be left unchanged.
    We route your message directly to the right team so you don’t get bounced around.

    Where To Buy
    Network-addressable power control and distribution units designed for remote management and integration with AV control systems. The IP Series allows for control and monitoring over standard IP networks via a web interface, TCP/IP, or UDP for simplified system automation.
    Intelligent Power Control for Any Space

    Service

    15A

    Outlets

    2 Switched

    Control

    Web, TCP/IP, UDP

    Protection

    RX Series Surge

    Form Factor

    Slimline
    REMOTE POWER CONTROL

    Reliable IP control and protection in a compact chassis.

    The iP 50-RX simplifies power management in space-constrained environments. It combines remote IP control over two independent outlets with the proven reliability of Juice Goose RX Series surge protection and power conditioning. The onboard web server provides an intuitive interface for setup and control from any browser, while support for TCP/IP and UDP commands allows for seamless integration with commercial and proprietary control systems.

    This compact unit is ideal for installations behind displays, in podiums, or small racks where reliable power and remote reboot capabilities are critical. By enabling scheduled power cycling and remote management, the iP 50-RX helps integrators reduce service calls, protect sensitive equipment from power anomalies, and improve system uptime.

    COMPATIBLE ACCESSORIES

    Integrate the iP 50-RX with your systems.

    The iP 50-RX is designed to work with a range of control systems and network equipment.

    Third-Party Control Systems

    Integrates with platforms like Crestron and AMX via direct TCP/IP or UDP text-based communication for automated control.

    Network Routers and Modems

    Use the auto-ping feature to automatically power cycle and reboot unresponsive network hardware, improving network uptime.

    DSPs and Digital Processors

    Provides clean, protected power and allows for remote reboots of processor-based electronics to resolve operational issues.

    Standard Web Browsers

    The onboard web server is accessible from any modern browser on your network for simple, direct control and configuration.
    WHY LYNTEC

    Simplified Power Management. Trusted Protection.

    • Remote reboot capability reduces costly service calls.
    • Patented RX Series protection for sensitive electronics.
    • Simple web interface for fast setup and operation.
    • Durable steel construction for long-term reliability.
    FEATURES

    iP 50-RX Features

    Explore the standard capabilities engineered into every iP 50-RX for reliable remote power management.
    CAPABILITIES

    Features

    Integrated Web Server

    Provides an intuitive graphical interface for control and monitoring from any web browser.

    Two Controllable Outlets

    Independently switch two AC receptacles on and off for precise remote power management.

    RX Series Surge Protection

    Patented hybrid filter technology protects against normal and common mode power anomalies.

    TCP/IP and UDP Control

    Integrates with commercial control systems using simple, text-based commands.

    Automatic Power Cycling

    Can be configured to automatically reboot a connected router if network connectivity is lost.

    Wiring Fault Detection

    Prevents power output if dangerous wiring conditions like a missing ground are detected.

    Compact Slimline Chassis

    Installs easily in tight spaces behind displays, in podiums, or small enclosures.
    01

    Control From Anywhere

    An onboard web server provides an intuitive browser-based interface for remote power switching, setup, and monitoring, reducing the need for on-site service calls.
    • Administrator and user login options
    • Control via any standard web browser
    • Automatic router reboot on network loss
    02

    Reliable by Design

    Features patented RX Series Hybrid Filter Technology to protect connected equipment from power surges and common mode noise without ground contamination.
    • Protects from surges up to 6,000V
    • Reduces let-through to less than 0.5V N-G
    • Prevents operation with wiring faults
    03

    Integrates With Your System

    Communicate directly with third-party control systems using simple text-based commands over TCP/IP or UDP for seamless automation.
    • Supports TCP/IP and UDP protocols
    • Enables scheduling and sequencing
    • Ideal for rebooting DSPs or processors
    SPECIFICATIONS

    iP 50-RX Specifications

    Review the detailed technical data for integrating the iP 50-RX into your power infrastructure.

    iP 50-RX Technical Specifications

    Key electrical, control, and physical details for the iP 50-RX remote power controller.

    Electrical

    • Load Capacity
      15A
    • Controllable Outlets
      2
    • Unswitched Outlets
      1
    • Power Protection
      RX Series Hybrid Filter Technology
    • Over Voltage Protection
      Shuts down above 150V

    Control

    • Network Interface
      Ethernet
    • Protocols
      HTTP (Web Server), TCP/IP, UDP
    • Local Indicators
      LEDs for Power, Network, Outlet Status, Protection

    Physical

    • Chassis
      Slimline, Steel Construction
    • Dimensions (H x W x D)
      1.75 in x 9.0 in x 9.5 in
    • Weight
      5 lbs
    • Mounting
      Side mounting flanges

    Questions or Concerns?

    Let us know, we’re here to help! Contact Us

    PRODUCT SUPPORT

    iP 50-RX Support

    Find manuals, datasheets, and other resources to assist with installation and operation.
    FAQ

    FAQs about the iP 50-RX

    Can this device reboot my network router automatically?

    Yes, it features an automatic power cycle function that can be configured to reboot a connected device, like a router, if it loses its network connection.

    How do I control the iP 50-RX?

    You can control it using its built-in web server from any browser, or integrate it with a control system using simple text commands over TCP/IP or UDP.

    What happens if there is a wiring problem at the outlet?

    The iP 50-RX includes wiring fault detection. It will not pass power to connected equipment if it detects incorrect wiring, over-voltage, or a missing ground connection.

    What kind of surge protection does it have?

    It includes Juice Goose’s patented RX Series Hybrid Filter Technology, which protects against both normal mode and common mode surges and noise without contaminating the ground line.

    Where is the iP 50-RX typically installed?

    Its compact, slimline chassis is designed for installation in tight spaces where remote control is needed, such as behind flat-panel displays, inside podiums, or in small equipment racks.

    NEXT Features
    BACK Overview NEXT Specifications
    BACK Features NEXT Product Support
    BACK Specifications NEXT Contact Us

    Need help with a specific application?

    Our team can help you determine if the iP 50-RX is the right fit for your installation. Contact us for technical guidance or to request a quote.
