    RX 100-20A

    Rack-mount power conditioner with 20A service and hybrid filter technology.

    The RX 100-20A is a commercial-grade power conditioner featuring hybrid filter technology to protect against surges and high-frequency interference on all power leads. It is designed for AV racks requiring robust 20A power protection with over-voltage shutdown and clean ground to ensure reliable equipment performance.

    Request a Quote

    Request A Quote

    Request more information about this product or speak directly with our sales team today.

    This field is for validation purposes and should be left unchanged.
    We route your message directly to the right team so you don’t get bounced around.

    Where To Buy
    Professional surge protection and power conditioning for sensitive AV and digital processing systems. The RX series uses a patented Hybrid Filter Technology to protect all three power lines (hot, neutral, ground) from both high-energy surges and low-level line noise.
    Engineered for Performance and Protection

    Service

    20A / 120V

    Outlets

    8 NEMA 5-20R

    Protection

    Hybrid Filter

    Form Factor

    1U Rack-Mount

    Surge Protection (L-N)

    6,000V at 3,000A Surge Rating
    POWER CONDITIONING

    Reliable protection for 20A rack-mounted systems.

    The RX 100-20A delivers dependable power conditioning for professional AVL racks. It integrates Juice Goose’s proven Hybrid Filter Technology, which actively protects connected equipment from damaging power surges and high-frequency noise across hot, neutral, and ground lines. This ensures a cleaner power signal, which is critical for the stable operation of sensitive digital audio and video components.

    Engineered for durability in demanding environments, the unit features a sturdy Tour Class chassis and provides over-voltage shutdown for an added layer of protection. With a maximum surge let-through of just 10 volts between line and neutral and only 0.5 volts on the ground, the RX 100-20A helps prevent operational failures and improves the performance of your entire system.

    SYSTEM COMPATIBILITY

    Integrate with your professional equipment.

    The RX 100-20A is designed to power and protect a wide range of AVL components.

    Standard 19-Inch Equipment Racks

    Mounts securely in any standard 1U rack space, perfect for both fixed and mobile setups.

    Professional Audio Gear

    Provides clean, protected power for mixers, amplifiers, and digital signal processors.

    Video and Broadcast Equipment

    Safeguards sensitive video switchers, recorders, and broadcast components from power anomalies.

    NEMA 5-20P and 5-15P Plugs

    The NEMA 5-20R outlets accept standard 20A and 15A plugs from connected devices.
    WHY JUICE GOOSE

    Engineered for protection and performance.

    • Hybrid Filter cleans power without contaminating the ground
    • Over-voltage shutdown protects against sustained damaging events
    • Tour Class chassis provides durability for mobile and fixed installs
    • Built on four decades of trusted power infrastructure experience
    FEATURES

    RX 100-20A Features

    A detailed look at the standard capabilities built into every RX 100-20A unit.
    CAPABILITIES

    Features

    20 Amp Capacity

    Provides robust power distribution for fully loaded professional audio and video racks.

    Hybrid Filter Technology

    Reduces common and normal mode noise for cleaner power and improved system performance.

    Advanced Surge Protection

    Limits voltage let-through to a maximum of 10V (L-N) and 0.5V on ground.

    Over-Voltage Shutdown

    Automatically disconnects power during sustained over-voltage events to protect equipment.

    Wiring Fault Protection

    Front-panel LED indicator alerts users to potentially hazardous external wiring issues.

    Eight AC Outlets

    Includes seven rear-panel and one front-panel NEMA 5-20R outlets for flexible connectivity.

    Tour Class Chassis

    Features a rugged, single-piece steel chassis built to withstand demanding environments.
    01

    Advanced Hybrid Filter

    Juice Goose’s proven Hybrid Filter Technology cleans power and protects against surges on hot, neutral, and ground lines without contaminating the ground.
    • Maximum 10V surge let-through (Line to Neutral)
    • Maximum 0.5V surge let-through on ground
    • Reduces common and normal mode noise
    02

    Comprehensive Safety Features

    Beyond filtration, the RX 100-20A includes multiple layers of protection to safeguard connected equipment from unpredictable power conditions.
    • Automatic over-voltage shutdown
    • Front-panel wiring fault indicator
    • Protects against surges up to 6,000V at 3,000A
    03

    Built for Professional Use

    With a rugged chassis and convenient layout, this unit is designed for the demands of both permanent installations and mobile touring rigs.
    • Sturdy, single-piece Tour Class steel chassis
    • Seven rear outlets and one front outlet
    • Reinforced mounting brackets
    SPECIFICATIONS

    RX 100-20A Specifications

    All the technical details needed for system design and integration.

    RX 100-20A Technical Specifications

    Detailed electrical, physical, and protection specifications for the RX 100-20A power conditioner.

    Electrical

    • Input Voltage
      120 VAC, 60 Hz
    • Current Rating
      20A
    • Outlets
      8x NEMA 5-20R (7 rear, 1 front)
    • Power Cord
      7-foot, 12/3 SJT

    Protection

    • Surge Let-Through (L-N)
      Maximum 10.0V
    • Surge Let-Through (Ground)
      Maximum 0.5V
    • Noise Filtration
      Normal and Common Mode
    • Over-Voltage Shutdown
      Included

    Physical

    • Chassis
      Tour Class cold-rolled steel
    • Form Factor
      1U Rack-Mount
    • Dimensions (W x D x H)
      19.0″ x 7.0″ x 1.75″
    • Weight
      8 lbs

    Questions or Concerns?

    Let us know, we’re here to help! Contact Us

    PRODUCT SUPPORT

    RX 100-20A Support

    Find datasheets, manuals, and answers to common questions about the RX 100-20A.
    FAQ

    FAQs about the RX 100-20A

    How does the Hybrid Filter Technology improve performance?

    The filter works on all three power leads (hot, neutral, ground) to reduce high-frequency noise and interference. Unlike other designs, it does not contaminate the ground line, which is critical for preventing issues with sensitive digital equipment.

    Is this unit suitable for touring and mobile racks?

    Yes. The RX 100-20A features a rugged, single-piece Tour Class steel chassis with reinforced mounting brackets, making it durable enough for the demands of mobile applications.

    What does the ‘Wiring Fault’ indicator mean?

    The wiring fault indicator illuminates to warn of potentially unsafe conditions in the building’s wiring, such as a missing ground connection or reversed polarity. This allows you to correct issues before they can damage equipment.

    What is the difference between the RX 100-20A and the RX 100-15A?

    The primary difference is the load capacity. The RX 100-20A is rated for 20 amp service, while the RX 100-15A is designed for 15 amp applications. Both feature the same Hybrid Filter and protection technologies.
