    SCV-30001 On-Line UPS (3000VA / 2700W)

    On-line, double-conversion UPS with 3000VA capacity for critical applications.

    The SCV-30001 is a true on-line, double-conversion uninterruptible power supply that provides stable, clean power by completely isolating equipment from grid disturbances. It is designed for mission-critical AVL and broadcast racks requiring reliable battery backup and protection for sensitive electronic systems against all power problems.

    Request a Quote

    Request A Quote

    Request more information about this product or speak directly with our sales team today.

    This field is for validation purposes and should be left unchanged.
    We route your message directly to the right team so you don’t get bounced around.

    Where To Buy
    On-line, double-conversion Uninterruptible Power Supply (UPS) systems designed to provide the highest level of power protection for mission-critical AVL, broadcast, and IT equipment in rack-mount applications.
    Engineered for Critical Uptime

    POWER CAPACITY

    3000VA / 2700W

    TOPOLOGY

    On-Line

    RACK HEIGHT

    2U

    RUNTIME (FULL)

    3 min

    WARRANTY

    3-Year Electronics
    ON-LINE UPS

    Reliable battery backup and power conditioning for critical systems.

    The SCV-30001 delivers the highest level of power protection with its true on-line, double-conversion architecture. This design creates a complete electrical firewall, regenerating clean, precise sine-wave power and ensuring connected systems are never exposed to raw utility power, including surges, sags, or frequency variations. An advanced 0.90 output power factor provides more real power (watts) for modern equipment, improving efficiency and reducing operating costs for your facility.

    Engineered for rack-mount deployment in broadcast, production, and performance venues, the SCV-30001 maintains uptime for your most sensitive electronics. The front-panel LCD provides at-a-glance status of load levels, battery health, and system parameters, while an optional SNMP card enables full remote monitoring and management.

    COMPATIBLE ACCESSORIES

    Expand your SCV-30001 installation.

    Add optional management cards and connect to standard broadcast and IT equipment.

    SCV-SNMP Network Card

    Enables remote IP-based monitoring, management, and automated shutdown capabilities.

    Standard 19-Inch Equipment Racks

    Installs into any standard 2U rack space using the included rail kit.

    NEMA L5-30R Receptacles

    Requires a dedicated 30A circuit for input power, common in server rooms and production facilities.

    Critical AVL and IT Equipment

    Protects servers, network switches, video recorders, and other sensitive electronics.
    CONFIGURATION OPTIONS

    Configure your UPS.

    Select optional components to match your monitoring and control requirements.
    Network Management

    Add remote monitoring and control capabilities to your UPS.

    • Optional SNMP Card (SCV-SNMP): Enables IP-based monitoring, management, and automated shutdown scripts for network-attached devices and servers.
    Mounting Hardware

    The SCV-30001 is ready for multiple deployment scenarios.

    • Rack Rails (Included): Ships with a complete rack rail mounting kit for standard 19-inch equipment racks.
    • Floor Stand (Included): Includes hardware for vertical tower orientation on the floor or a shelf.
    WHY JUICE GOOSE

    Dependable power infrastructure for AVL systems.

    • True on-line design for complete power isolation
    • High 0.9 power factor for efficient operation
    • 3-year electronics, 1-year battery warranty
    • US-based support for specification and installation
    FEATURES

    SCV-30001 UPS Features

    Standard capabilities designed to deliver reliable power and operational visibility for critical applications.
    CAPABILITIES

    Features

    On-Line Double Conversion

    Provides the highest level of power protection by completely regenerating incoming AC power.

    3000VA / 2700W Capacity

    Supports significant loads in critical AVL, broadcast, and IT rack environments.

    High Power Factor (0.9)

    Delivers more real power to modern electronics, improving efficiency and performance.

    Rack Mountable 2U Design

    Installs easily into standard equipment racks with included mounting hardware.

    User-Replaceable Batteries

    Allows for hot-swappable battery replacement without powering down connected equipment.

    Informative LCD Display

    Provides immediate, detailed information on UPS status, load, and battery condition.

    Optional SNMP Network Card

    Enables remote monitoring, management, and automated shutdown of network devices.

    Emergency Power Off (EPO)

    Allows for immediate shutdown of the UPS in an emergency situation.
    01

    True Double-Conversion Protection

    Completely isolates connected equipment from raw utility power, providing the highest level of protection against all power disturbances.
    • Zero transfer time to battery
    • Regenerates clean, stable sine-wave power
    • Protects against surges, sags, and noise
    02

    Efficient Power for Modern Loads

    A high 0.9 output power factor delivers more real wattage to your equipment, maximizing the UPS capacity and reducing energy waste.
    • Supports modern power factor corrected (PFC) supplies
    • Reduces UPS and facility operating costs
    • 90% efficiency in on-line mode
    03

    Clear Visibility and Control

    An intuitive front-panel LCD and optional network management card provide comprehensive status monitoring and remote control capabilities.
    • Real-time load and battery level display
    • Audible alarms for critical events
    • Optional SNMP card for remote management
    SPECIFICATIONS

    SCV-30001 UPS Specifications

    Review the detailed technical data for integration into your power infrastructure.

    SCV-30001 Technical Specifications

    Detailed electrical, physical, and communication specifications for the SCV-30001 UPS.

    Output

    • Power Capacity
      3000VA / 2700W
    • Nominal Output Voltage
      120V
    • Output Waveform
      Pure Sine Wave
    • Output Connections
      (1) NEMA L5-30R, (6) NEMA 5-20R

    Input

    • Nominal Input Voltage
      120V
    • Input Frequency
      50/60 Hz
    • Input Connection
      NEMA L5-30P
    • Required Service
      30A Dedicated Circuit

    Battery and Runtime

    • Battery Type
      Sealed Lead-Acid
    • Hot-Swappable Batteries
      Yes
    • Runtime at Full Load
      3 minutes
    • Runtime at Half Load
      10 minutes

    Physical

    • Form Factor
      Rack Mount 2U / Tower
    • Weight
      65 lbs (29.5 kg)

    Questions or Concerns?

    Let us know, we’re here to help! Contact Us

    PRODUCT SUPPORT

    SCV-30001 UPS Support

    Find manuals, datasheets, and other resources to help you deploy and manage your UPS.
    FAQ

    FAQs about the SCV-30001 UPS

    Can I replace the batteries myself?

    Yes, the batteries are user-replaceable and hot-swappable. You can change them without shutting down the UPS or your connected equipment, ensuring continuous operation.

    How do I monitor the UPS remotely?

    Remote monitoring requires the optional SCV-SNMP network card. Once installed, the UPS can be managed over your IP network using the included SentryHD software or other SNMP-compatible platforms.

    What is on-line, double-conversion technology?

    It’s the highest level of UPS protection. The UPS continuously converts incoming AC power to DC, then back to perfect AC, completely isolating your gear from all power problems with zero transfer time to battery.

    What is the warranty on the SCV-30001?

    The UPS electronics are covered by a three-year warranty, and the internal batteries are covered by a one-year warranty. Contact LynTec support for service details.

    What kind of electrical service does this UPS require?

    The SCV-30001 requires a dedicated 30A, 120V circuit with a NEMA L5-30R receptacle. It cannot be plugged into a standard 15A or 20A wall outlet.
