RPC 341

Remote Setup, Control, and Monitoring in One Panel

The most advanced self-contained controllable breaker panel on the market today. The RPC combines all the features you’ve come to expect from LynTec panels with new web enabled control and monitoring capabilities. Based on the G3 PowerlinkTM hardware platform by Square D, the RPC uses the latest remotely operated breakers and can control up to 168 circuit breakers with a single controller. In addition, the RPC’s expanded interface options (DMX, sACN, HTTP, Telnet, RS-232 or BacNET (optional)) allow users to monitor and control the system from any remote location.

  • New programmable software platform (patent pending) can be customized for optimal power management.
  • So simple to set up, no on-site factory commissioning is required.
  • Control circuits individually, or establish up to 12 breaker group zones.
  • Built in scheduling program with astronomical clock for timed zone control.
  • Built in IP browser interface for smart phone, tablet or laptop control and monitoring.
  • Built in contact closure inputs for wall switch or sensor operation.
  • Circuit level load-shedding feature standard.
  • Circuit level sequencing with selectable step-rates standard.
  • Circuit selectable auto-on egress lighting feature standard (ETL listed UL 924)
  • Circuit selectable brown-out (under-voltage) protection standard.
  • High current contactor control via I/O/R card optional.
  • SurgeX in-panel surge elimination modules available as an option.
  • Current monitoring and reporting available as an option.
  • Plug-on control bus strips simplify wiring and installation.
  • 120/208V, 240V or 277/480V operation.
  • 200% Neutrals standard
  • 225A Main Standard (150A  to 400A or MLO versions optional)
  • Easy setup for sequential system control of audio systems or individual circuit control of non-dimmed lighting circuits.
  • The LynTec isolated technical ground bar reduces electrical noise and improves sound system performance.
  ETL_Safety

30 Circuit Panels

RPC 341 & RPC 329

Master Panel:

Secondary Panels:

42 Circuit Panels

Master Panels:

Secondary Panels:

48 Circuit Panels  (48 controlled circuits + 6 additional uncontrolled circuits)

Master Panel:

Secondary Panels:

66 Circuit Panels

Master Panel:

Secondary Panels:

84 Circuit Panels

Master Panel:

Secondary Panel:

For powered secondary panels add “P” suffix.

IPC Integrated Power Center

The RPC is also available in an integrated enclosure that combines an isolation transformer and up to 84 circuit breakers into a single standing floor unit.  Each panel is custom built to your specification.  Call or write for more information.

Control Options
Click here to tour our interactive virtual RPC GUI.


TCP/IP DMX sACN RS-232 The RPC can work with any external controller that uses DMX, sACN, TCP/IP or RS-232 control protocols.

Square D’s Powerlink Breaker

  • Robust construction and highly effective trip mechanism provide unequaled remote operation capability in terms of electrical ratings and mechanical life (rated for 200,000 cycles).
  • Motorized mechanism can open and close the contacts when the circuit breaker handle is in the ON position.
  • Contacts cannot be closed remotely when the handle is in the OFF position or the circuit breaker is tripped.
  • Manual override selector located on the front of the circuit breaker– necessary when emergency power control is required.
  • Contact status indication – this superior capability assures the true status of the branch circuit is reflected back to the remote location.
  • Available in 15, 20, and 30 A, one, two and three poles.

RPC One Page Factsheet

RPC Technical and Submittal Info

RPC Brochure

RPC Operations Manual

RPC v1 Operations Manual— for systems shipped prior to November 2014

RPC A&E Specs – PDF file or Word document

QuickStart Guides:

Multi-Panel Setup Quickstart Guide

RPC Quickstart Guide

Contact Closure Quickstart Guide

Optional Features:

Narrow Profile Panelboard Factsheet

High Current Contactor Control Option

SurgeX  In-panel Surge Elimination Option

Current Monitoring and Reporting Option

IPC Integrated Power Center Option

Full Catalog Download



Click thumbnail to view.

Whole Venue Control

Whole Venue Control

Whole Venue Control allows clients the ability to mix and match our robust RPC Remote Motorized Panels, RPCR Relay Panel Systems, and new NPAC Multi-Circuit Rackmount units all together on a single network for a user-friendly interface. Control your entire venue with ease!

Narrow Profile Overview

LynTec Narrow Profile Panel Overview

This video introduces the new Narrow Profile Panel configuration from LynTec for the RPC and LCP Series of motorized circuit breaker panels.

LYNTEC Load Shedding and Peak Shaving Panel

LYNTEC Load Shedding and Peak Shaving Panel

LynTec’s RPC line of remote control circuit breaker and relay panels has the ability to load shed at the circuit level as a standard feature. It can shed circuits in an under-voltage or brownout condition, or turn selected circuits off with a contact closure input. Circuits can then be sequenced back on when it’s safe.

RPC Setup (1/6) Hardware

RPC Setup (1/6) Hardware

Brief overview of basic RPC panel hardware and set-up. Includes hardware tour, low voltage wiring, powering and connecting to your control network (TCP/IP, RS-232, DMX512).

RPC Setup (2/6) Secondary Panels

RPC Setup (2/6) Secondary Panels

Brief overview of connecting secondary panels and matching the GUI to your physical configuration. Includes hardware involved, wiring instruction and software scan-for-breakers command.

RPC Setup (3/6) Initial Network Setup

RPC Setup (3/6) Initial Network Setup

Part three of our RPC setup series covers initial network setup and brief description of available options/tools.

RPC Setup (4/6) Zone Setup

RPC Setup (4/6) Zone Setup

Learn the basics of zone setup in Part Four of our RPC Setup series..

RPC Setup (5/6) Advanced Zone Setup

RPC Setup (5/6) Advanced Zone Setup

Learn the advanced zone setup in Part Five of our RPC Setup series

RPC Setup (6/6) Advanced Options and Accessories

RPC Setup (6/6) Advanced Options & Accessories

A quick overview of the RPC I/OR board and it’s capabilities. Includes control of contactors, outlets and LynTec legacy panels like the PDS, MSLC or MSP.

Single Address DMX

Single Address DMX

A brief overview and setup instructions for Single Address DMX.

Integrated Power Center - Single Cabinet Solution

Integrated Power Center – Single Cabinet Solution

See the IPC at a glance – an elegant way to package a very common panelboard(s) + transformer design.

Power Control Simplified

Power Control Simplified

LynTec Panel Basics: Why a controllable breaker panel? Square D motorized branch circuit breakers plus LynTec customized control electronics provides the most elegant electrical power control platform.

Controllable Motorized Circuit Breaker Tutorial

Controllable Motorized Circuit Breaker Tutorial

LynTec uses Square D manufactured remotely operated motorized branch circuit breakers to build custom AC power control systems for the pro A/V industry.

iPhone App Info

iPhone App Info

iPhone App for LynTec RPC Panels
